Intel OPA 48p Managed Switch
New: 12-month warranty, manufacturer-backed and mirrored locally (longer where the manufacturer's own warranty is longer).
30-day returns on unopened items — you arrange the courier; we pay it on faulty or dead-on-arrival units.
Intel OPA 48p Managed Switch.
Device Type: Switch - 48 ports - Managed. Enclosure Type: Rack-mountable 1U. Subtype: 100 Gigabit Ethernet. Ports: 48 x 100 Gigabit QSFP28. Performance: Throughput: 9.6 Tbps. Features: Adaptive routing, redundant fans, 6 fans. Status Indicators: Port status, power, system, link/activity. Interfaces: 48 x 100Gbit LAN QSFP28; 1 x 1000Base-T; 1 x USB.
Specifications
Highlights
- 48 x 100 Gigabit QSFP28 interfaces
- High switching throughput of up to 9.6 Tbps
- Compact 1U rack-mountable chassis with mounting kit included
- Adaptive routing capability for optimised traffic flow
- Dual redundant 238W power supplies with 1+1 redundancy
- Six integrated redundant cooling fans
Power
- Power Device
- Internal power supply
- Installed Qty
- 2
- Max Supported Qty
- 2
- Power Redundancy
- Yes
- Power Redundancy Scheme
- 1+1
- Power Provided
- 238 Watt
- Voltage Required
- AC 120/230 V (50/60 Hz)
General
- Device Type
- Switch - 48 ports - Managed
- Enclosure Type
- Rack-mountable 1U
- Subtype
- 100 Gigabit Ethernet
- Ports
- 48 x 100 Gigabit QSFP28
- Performance
- Throughput: 9.6 Tbps
- Features
- Adaptive routing, redundant fans, 6 fans
- Status Indicators
- Port status, power, system, link/activity
Dimensions & Weight
- Width
- 43.96 cm
- Depth
- 42.67 cm
- Height
- 4.32 cm
- Weight
- 7.01 kg
Environmental Parameters
- Min Operating Temperature
- 5 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 - 85%
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
Expansion / Connectivity
- Interfaces
- 48 x 100Gbit LAN QSFP28
- Interfaces
- 1 x 1000Base-T
- Interfaces
- 1 x USB
Manufacturer Warranty
- Service & Support
- Limited warranty - 3 years - on-site - response time: next business day
Miscellaneous
- Rack Mounting Kit
- Included
- Compliant Standards
- TUV, BSMI CNS 13438 Class A, EN 61000-3-2, EN 61000-3-3, EN55024, CISPR 22, UL 60950-1, EN 60950-1, REACH, FCC Part 15 B Class A, KCC Class A, NRTL, VCCI Class A, NMB-3 Class A, AS/NZS CISPR 22, CU-TR, RRA Class A, CSA 22.2 No. 60950-1, CAN ICES-3 Class A, CISPR32/EN55032, RoHS 2 (2011/65/EU), KN32, KN35
Related Products
Mellanox ConnectX-3 CX353A-FCBT Single-Port 40GB QSFP+ PCIe 3.0 x8 NIC Half Hght
Teltonika TRB145 LTE Cat1 RS485 Gateway
Teltonika TRB142 LTE Cat 1, 1 x LAN (1 Gbps), RS232 Gateway
Teltonika RUTX12 Cat 6 x 2 Industrial Router,Dual-SIM, Wi-FI 5, 1 x WAN(1 Gbps), 4 x LAN(1 Gbps), MQTT, MODBUS
The Intel OPA 48p Managed Switch from HPE is a 1U rack-mountable 100 Gigabit Ethernet network switch featuring 48 QSFP28 ports and 9.6 Tbps total throughput. Built for enterprise data centres and high-performance computing clusters, it provides adaptive routing, dual 1+1 redundant power supplies, and six redundant cooling fans for high-reliability network environments.
Frequently asked questions
What is the Intel OPA 48-port switch used for?
- It is a high-bandwidth 100GbE managed switch designed for enterprise data centres, compute clusters, and demanding networking environments. With 48 QSFP28 ports and 9.6 Tbps throughput, it delivers ultra-fast interconnectivity across networked systems.
What power redundancy features does this switch include?
- This switch is equipped with two internal 238 Watt power supplies configured in a 1+1 redundancy scheme. This setup ensures continuous operation and uninterrupted network availability even if a single power unit fails.
Does the Intel OPA 48p switch come with a warranty?
- Yes, it is covered by a 3-year limited warranty featuring on-site service and next business day response. South African customers can rely on dedicated local warranty support via Server Hub.
