HPE SN6010C 12-port 16Gb FC Switch
New: 12-month warranty, manufacturer-backed and mirrored locally (longer where the manufacturer's own warranty is longer).
30-day returns on unopened items — you arrange the courier; we pay it on faulty or dead-on-arrival units.
HPE SN6010C 12-port 16Gb FC Switch.
Device Type: Switch - 12 ports - Managed. Enclosure Type: Rack-mountable 1U. Subtype: Fibre Channel. Ports: 12 x 16Gb Fibre Channel SFP+. Performance: Aggregate bandwidth: 192 Gbps. Fibre Channel: FC-AL, FC-AL-2, FC-BB, FC-DA, FC-FLA, FC-FS, FC-GS, FC-GS-3, FC-GS-4, FC-MI, FC-PH, FC-PH-2, FC-PH-3, FC-PLDA, FC-SB-2, FC-SB-3, FC-SW-2, FC-SW-3, FC-Tape, FC-VI, FC-SP, FCP-4, FC-BB-2, FCP, FCP-2, FC-PI-2, FC-BB-3, FC-FS-2, FC-GS-5, FC-SW-4, FCP-3, FC-LS, FC-MI-2, FC-PI-4, FC-FS-3, FC-GS-6, FC-PI-3, FC-SW-5. Remote Management Protocol: SNMP, SNMP 3, SMI-S, CLI. Encryption Algorithm: AES.
Specifications
Highlights
- 12 x 16Gb Fibre Channel SFP+ ports
- 192 Gbps aggregate bandwidth performance
- Compact 1U rack-mountable enclosure
- Dual 300W hot-plug redundant power supplies
- LUN zoning, trunking, and Quality of Service support
- Remote management via CLI, SNMPv3, SMI-S, and Gigabit LAN
Power
- Power Device
- Internal power supply - hot-plug
- Installed Qty
- 2
- Max Supported Qty
- 2
- Power Redundancy
- Yes
- Power Provided
- 300 Watt
- Voltage Required
- AC 120/230 V (50/60 Hz)
General
- Device Type
- Switch - 12 ports - Managed
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Fibre Channel
- Ports
- 12 x 16Gb Fibre Channel SFP+
- Performance
- Aggregate bandwidth: 192 Gbps
- Fibre Channel
- FC-AL, FC-AL-2, FC-BB, FC-DA, FC-FLA, FC-FS, FC-GS, FC-GS-3, FC-GS-4, FC-MI, FC-PH, FC-PH-2, FC-PH-3, FC-PLDA, FC-SB-2, FC-SB-3, FC-SW-2, FC-SW-3, FC-Tape, FC-VI, FC-SP, FCP-4, FC-BB-2, FCP, FCP-2, FC-PI-2, FC-BB-3, FC-FS-2, FC-GS-5, FC-SW-4, FCP-3, FC-LS, FC-MI-2, FC-PI-4, FC-FS-3, FC-GS-6, FC-PI-3, FC-SW-5
- Remote Management Protocol
- SNMP, SNMP 3, SMI-S, CLI
- Encryption Algorithm
- AES
- Authentication Method
- RADIUS, TACACS+, Secure Shell v.2 (SSH2)
- Features
- Trunking, Syslog support, LUN zoning, Quality of Service (QoS), redundant hot swappable fans, MAC and IP-based ACLs support
Dimensions & Weight
- Width
- 43.59 cm
- Depth
- 47.98 cm
- Height
- 4.47 cm
- Weight
- 10 kg
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 5 - 95% (non-condensing)
Expansion / Connectivity
- Interfaces
- 12 x 16Gb Fibre Channel SFP+
- Interfaces
- 1 x management (Gigabit LAN)
- Interfaces
- 1 x management (RS-232)
Manufacturer Warranty
- Service & Support
- Limited warranty - parts and labour - 1 year - on-site - response time: next business day
Miscellaneous
- Compliant Standards
- ETSI, CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, EN50082-1, EN 61000-6-1, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825, AS/NZS 60950, IEC 60825, VCCI Class A, KN24, AS/NZS CISPR 22, ETSI 300 019, CAN/CSA-C22.2 No. 60950-1
Software / System Requirements
- Software Included
- Cisco Data Center Network Manager
- OS Required
- Cisco MDS 9000 NX-OS 6.2(9) or later
Related Products
Mellanox ConnectX-3 CX353A-FCBT Single-Port 40GB QSFP+ PCIe 3.0 x8 NIC Half Hght
Teltonika TRB145 LTE Cat1 RS485 Gateway
Teltonika TRB142 LTE Cat 1, 1 x LAN (1 Gbps), RS232 Gateway
Teltonika RUTX12 Cat 6 x 2 Industrial Router,Dual-SIM, Wi-FI 5, 1 x WAN(1 Gbps), 4 x LAN(1 Gbps), MQTT, MODBUS
The HPE SN6010C is a managed 1U rack-mountable Fibre Channel switch equipped with 12 x 16Gb SFP+ ports delivering up to 192 Gbps aggregate bandwidth. Built for storage area networks requiring high-speed data connectivity, it provides enterprise capabilities including LUN zoning, port trunking, dual redundant hot-plug power supplies, and AES encryption.
Frequently asked questions
What is the HPE SN6010C switch used for?
- The HPE SN6010C is designed for dedicated Storage Area Networks (SANs), connecting host servers to enterprise storage arrays. It provides 16Gb Fibre Channel connectivity across 12 SFP+ ports to maintain high-throughput and low-latency storage traffic.
Does the HPE SN6010C support hardware redundancy?
- Yes, the switch features two installed 300W hot-plug power supplies for full 1+1 power redundancy. It is also equipped with redundant hot-swappable cooling fans to maintain continuous uptime in rack environments.
Does the switch come with a warranty in South Africa?
- Yes, this product is backed by a local South African warranty through Server Hub. It includes parts and labour coverage with next-business-day on-site response.
