SPT-78FEACE26396D7
HPE 5520 24G SFP 4SFP+ HI Swch
R 410 700
Available to order
3–7 day deliveryNew: 12-month warranty, manufacturer-backed and mirrored locally (longer where the manufacturer's own warranty is longer).
30-day returns on unopened items — you arrange the courier; we pay it on faulty or dead-on-arrival units.
Quantity
1
HPE 5520 24G SFP 4SFP+ HI Swch.
Device Type: Switch - 24 ports - L3 - Managed - stackable. Enclosure Type: Side to back airflow rack-mountable 1U. Subtype: 10 Gigabit Ethernet. Ports: 24 x combo Gigabit SFP + 4 x 1 Gigabit / 10 Gigabit SFP+. Performance: Latency (1000 Mbps): 5 µs; Latency (10 Gbps): 3 µs; Throughput: 180 Mbps; Routing/switching capacity: 288 Gbps. Capacity: IPv4 routing table entries: 32768; IPv6 routing table entries: 16384. MAC Address Table Size: 64K entries. Jumbo Frame Support: 10000 bytes.
Specifications
- RAM
- 2 GB SDRAM
Highlights
- 24 combo Gigabit SFP ports with 4 high-speed 1G/10G SFP+ uplink slots
- Layer 3 dynamic routing engine supporting OSPF, BGP, RIP, and MPLS
- 288 Gbps total switching capacity with low-latency packet forwarding
- Stackable architecture supporting up to 9 physical units in a single stack
- 1U rack-mountable chassis featuring side-to-back airflow and hot-plug dual PSU support
Power
- Power Device
- Internal power supply (not installed) - hot-plug
- Max Supported Qty
- 2
- Power Provided
- 2 A
- Voltage Required
- AC 100-240 V (50/60 Hz)
General
- Device Type
- Switch - 24 ports - L3 - Managed - stackable
- Enclosure Type
- Side to back airflow rack-mountable 1U
- Subtype
- 10 Gigabit Ethernet
- Ports
- 24 x combo Gigabit SFP + 4 x 1 Gigabit / 10 Gigabit SFP+
- Performance
- Latency (1000 Mbps): 5 µs
- Performance
- Latency (10 Gbps): 3 µs
- Performance
- Throughput: 180 Mbps
- Performance
- Routing/switching capacity: 288 Gbps
- Capacity
- IPv4 routing table entries: 32768
- Capacity
- IPv6 routing table entries: 16384
- MAC Address Table Size
- 64K entries
- Jumbo Frame Support
- 10000 bytes
- Max Units In A Stack
- 9
- Routing Protocol
- OSPF, RIP, IS-IS, BGP, IGMPv2, IGMP, VRRP, PIM-SM, static IP routing, PIM-DM, IGMPv3, OSPF for IPv6, OSPFv3, PIM-SSM, static IPv4 routing, static IPv6 routing, ECMP, RIPng, IS-ISv6, BGP-4+, MPLS, Bidirectional Forwarding Detection (BFD), CIDR
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, SSH-2, CLI, SCP, SNMP 6, NTP, ICMP, DHCP, RADIUS
- Encryption Algorithm
- SSL
- Authentication Method
- Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2), HWTACACS
- Features
- Flow control, Layer 3 switching, DHCP support, BOOTP support, ARP support, MPLS support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DiffServ support, Weighted Round Robin (WRR) queuing, IPv6 support, full duplex mode, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) su
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1v, ANSI/TIA-1057, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1r
- RAM
- 2 GB SDRAM
- Flash Memory
- 512 MB
- Status Indicators
- Power, system, operation mode
Dimensions & Weight
- Width
- 43.99 cm
- Depth
- 36 cm
- Height
- 4.37 cm
- Weight
- 6.6 kg
Environmental Parameters
- Min Operating Temperature
- -5 °C
- Max Operating Temperature
- 45 °C
- Humidity Range Operating
- 5 - 95% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 5 - 95% (non-condensing)
Expansion / Connectivity
- Interfaces
- 24 x 1000Base-T / 1000Base-X SFP
- Interfaces
- 4 x Gigabit / 10Gbit LAN SFP+
- Interfaces
- 1 x serial (console)
- Interfaces
- 1 x management RJ-45
- Interfaces
- 1 x USB 2.0
- Expansion Slots
- 1 (total) / 1 (free) x Expansion Slot
- Installed Modules Qty (Max)
- 0 (installed) / 1 (max)
Manufacturer Warranty
- Service & Support
- Limited warranty - lifetime
Miscellaneous
- Rack Mounting Kit
- Included
- Compliant Standards
- EN55024, AS/NZS 60950-1, RoHS, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, GB 4943, EN 61000-4-29, ANSI C63.4-2009, EN 60825-2, IPv6 Ready, EN 61000-3-3:2008, EN 61000-3-2:2006+A1:2009+A2:2009, EAC, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-11:2004, EN 300 386 V1.6.1, EMC 2004/108/EC, VCCI V-3/2013.04 Class A, CISPR 24:2010, EN 55022:2010, CISPR 22:2008, EN 300 386, FDA 21 CFR, VCCI V-3/2012.04, EN 61000-4-3:2006, CAN/CSA-C22.2 No. 60950-1, EN 61000-4-4:2012
- Pricing Type
- CTO
Related Products
Apple
iPhone 17E Silicone Case with MagSafe - Black
3–7 day delivery
R 1 220Available
Apple
Apple Power Adapter Extension Cable
3–7 day delivery
R 459Available
rct
RCT Peripherals 32-70 Inch Low Profile Tilt TV Wall Mount
3–7 day delivery
R 260
zebra
Zebra 6-inch Waterproof DC Power Extension Cable for Screen Blanking
Ships in 10–15 business days
R 3 920Available
The HPE 5520 24G SFP 4SFP+ HI is an enterprise-grade 1U rack-mountable Layer 3 managed switch engineered for core, distribution, or aggregation networking layers. Featuring 24 combo Gigabit SFP ports and 4 dedicated 10G SFP+ uplink ports, it delivers robust 288 Gbps switching capacity and stacking capabilities for medium to large enterprise network infrastructures.
Frequently asked questions
What is the HPE 5520 24G SFP 4SFP+ HI switch used for?
- This switch is designed for enterprise aggregation, campus distribution, or high-performance core switching. It provides high-density fibre connectivity via 24 combo Gigabit SFP ports alongside 10 Gigabit SFP+ uplinks to efficiently handle bandwidth-heavy network traffic.
Can multiple HPE 5520 HI switches be stacked together?
- Yes, the HPE 5520 HI series supports stacking of up to 9 units. This allows network administrators to manage multiple physical switches as a single logical entity, improving redundancy and operational scalability.
Does this switch come with a warranty in South Africa?
- Yes, hardware purchases include local South African warranty support provided through Server Hub, ensuring rapid technical assistance and peace of mind for your infrastructure investments.
