SPT-89CB15910BE19D
HPE 5520 24G PoE+ 4SFP+ HI Swch
R 149 570
Available to order
3–7 day deliveryNew: 12-month warranty, manufacturer-backed and mirrored locally (longer where the manufacturer's own warranty is longer).
30-day returns on unopened items — you arrange the courier; we pay it on faulty or dead-on-arrival units.
Quantity
1
HPE 5520 24G PoE+ 4SFP+ HI Swch.
Device Type: Switch - 24 ports - L3 - Managed - stackable. Enclosure Type: Rack-mountable 1U. Subtype: 10 Gigabit Ethernet. Ports: 24 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+. Power Over Ethernet (PoE): PoE+. PoE Budget: 720 W. Performance: Latency (1000 Mbps): 5 µs; Latency (10 Gbps): 3 µs; Throughput: 180 Mbps; Routing/switching capacity: 288 Gbps. Capacity: IPv4 routing table entries: 32768; IPv6 routing table entries: 16384.
Specifications
- RAM
- 2 GB SDRAM
Highlights
- 24 x Gigabit PoE+ ports with a 720W total power budget
- 4 x 1G/10G SFP+ high-speed uplink ports
- 288 Gbps routing and switching capacity with low latency
- Stackable architecture supporting up to 9 units
- Advanced Layer 3 routing including OSPF, BGP, and IPv6
- Dual hot-plug power supply support in a 1U rackmount chassis
Power
- Power Device
- Internal power supply (not installed) - hot-plug
- Max Supported Qty
- 2
- Power Provided
- 3 A
- Voltage Required
- AC 100-240 V (50/60 Hz)
General
- Device Type
- Switch - 24 ports - L3 - Managed - stackable
- Enclosure Type
- Rack-mountable 1U
- Subtype
- 10 Gigabit Ethernet
- Ports
- 24 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 720 W
- Performance
- Latency (1000 Mbps): 5 µs
- Performance
- Latency (10 Gbps): 3 µs
- Performance
- Throughput: 180 Mbps
- Performance
- Routing/switching capacity: 288 Gbps
- Capacity
- IPv4 routing table entries: 32768
- Capacity
- IPv6 routing table entries: 16384
- MAC Address Table Size
- 64K entries
- Jumbo Frame Support
- 10000 bytes
- Max Units In A Stack
- 9
- Routing Protocol
- OSPF, RIP, IS-IS, BGP, IGMPv2, IGMP, VRRP, PIM-SM, static IP routing, PIM-DM, IGMPv3, OSPF for IPv6, OSPFv3, PIM-SSM, static IPv4 routing, static IPv6 routing, ECMP, RIPng, IS-ISv6, BGP-4+, MPLS, Bidirectional Forwarding Detection (BFD), CIDR
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, SSH-2, CLI, SCP, SNMP 6, NTP, ICMP, DHCP, RADIUS
- Encryption Algorithm
- SSL
- Authentication Method
- Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2), HWTACACS
- Features
- Flow control, Layer 3 switching, DHCP support, BOOTP support, ARP support, MPLS support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DiffServ support, Weighted Round Robin (WRR) queuing, IPv6 support, full duplex mode, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) su
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1v, ANSI/TIA-1057, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1r
- RAM
- 2 GB SDRAM
- Flash Memory
- 512 MB
- Status Indicators
- Power, system, operation mode
Dimensions & Weight
- Width
- 44 cm
- Depth
- 46 cm
- Height
- 4.37 cm
- Weight
- 9.2 kg
Environmental Parameters
- Min Operating Temperature
- -5 °C
- Max Operating Temperature
- 45 °C
- Humidity Range Operating
- 5 - 95% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 5 - 95% (non-condensing)
Expansion / Connectivity
- Interfaces
- 24 x 1000Base-T RJ-45 PoE+
- Interfaces
- 4 x Gigabit / 10Gbit LAN SFP+
- Interfaces
- 1 x serial (console)
- Interfaces
- 1 x management RJ-45
- Interfaces
- 1 x USB 2.0
- Expansion Slots
- 1 (total) / 1 (free) x Expansion Slot
- Installed Modules Qty (Max)
- 0 (installed) / 1 (max)
Manufacturer Warranty
- Service & Support
- Limited warranty - lifetime
Miscellaneous
- Rack Mounting Kit
- Included
- Compliant Standards
- EN55024, AS/NZS 60950-1, RoHS, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, GB 4943, EN 61000-4-29, ANSI C63.4-2009, EN 60825-2, IPv6 Ready, EN 61000-3-3:2008, EN 61000-3-2:2006+A1:2009+A2:2009, EAC, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-11:2004, EN 300 386 V1.6.1, EMC 2004/108/EC, VCCI V-3/2013.04 Class A, CISPR 24:2010, EN 55022:2010, CISPR 22:2008, EN 300 386, FDA 21 CFR, VCCI V-3/2012.04, EN 61000-4-3:2006, CAN/CSA-C22.2 No. 60950-1, EN 61000-4-4:2012
- Pricing Type
- CTO
Related Products
Apple
iPhone 17E Silicone Case with MagSafe - Black
3–7 day delivery
R 1 220Available
Apple
Apple Power Adapter Extension Cable
3–7 day delivery
R 459Available
rct
RCT Peripherals 32-70 Inch Low Profile Tilt TV Wall Mount
3–7 day delivery
R 260
zebra
Zebra 6-inch Waterproof DC Power Extension Cable for Screen Blanking
Ships in 10–15 business days
R 3 920Available
The HPE 5520 24G PoE+ 4SFP+ HI is a 1U managed Layer 3 stackable enterprise switch engineered for campus and branch networks requiring resilient power and high-speed aggregation. Featuring 24 Gigabit PoE+ ports with a 720W budget and 4 dedicated 10G SFP+ uplinks, it delivers robust 288 Gbps routing capacity for IP phones, wireless access points, and business-critical infrastructure.
Frequently asked questions
What is the HPE 5520 24G PoE+ HI switch used for?
- It is designed as an enterprise-grade access or aggregation switch for powering and connecting high-density network devices. With 24 PoE+ ports and a 720W budget, it easily handles IP cameras, Wi-Fi access points, and VoIP hardware while providing 10G uplinks to core network infrastructure.
Can the HPE 5520 24G PoE+ switch be stacked with other units?
- Yes, this switch supports stacking of up to 9 units for simplified management and increased port density across your network. It also offers advanced Layer 3 routing protocols such as OSPF, BGP, and MPLS.
Does this HPE switch come with a warranty?
- Yes, it is covered by a local South African warranty backed through Server Hub alongside HPE's limited lifetime hardware support. All orders are priced and invoiced in South African Rand.
