SPT-449B28BB6BA499
HPE 5140 48G PoE+ 4SFP+ EI Sw
R 163 480
Available to order
3–7 day deliveryNew: 12-month warranty, manufacturer-backed and mirrored locally (longer where the manufacturer's own warranty is longer).
30-day returns on unopened items — you arrange the courier; we pay it on faulty or dead-on-arrival units.
Quantity
1
HPE 5140 48G PoE+ 4SFP+ EI Sw.
Device Type: Switch - 52 ports - L3 - smart. Enclosure Type: Rack-mountable 1U. Subtype: Gigabit Ethernet. Ports: 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+. Power Over Ethernet (PoE): PoE+. PoE Budget: 370 W. Performance: Latency (1000 Mbps): 5 µs; Latency (10 Gbps): 3 µs; Throughput: 132 Mpps; Routing/switching capacity: 176 Gbps. Capacity: IPv4 routing table entries: 512; IPv6 routing table entries: 256; VLAN IDs: 4094.
Specifications
- RAM
- 512 MB SDRAM
Highlights
- 48 x 10/100/1000Base-T PoE+ ports and 4 x 10G/1G SFP+ uplink slots
- 370W total Power over Ethernet (PoE+) power budget
- 176 Gbps routing/switching capacity with 132 Mpps throughput
- Layer 3 routing capabilities including OSPF, RIP, and static IPv4/IPv6
- Compact 1U rack-mountable chassis with included rack mounting kit
Power
- Power Device
- Internal power supply
- Power Provided
- 478 Watt
- Voltage Required
- AC 100-240 V (50/60 Hz)
General
- Device Type
- Switch - 52 ports - L3 - smart
- Enclosure Type
- Rack-mountable 1U
- Subtype
- Gigabit Ethernet
- Ports
- 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+
- Power Over Ethernet (PoE)
- PoE+
- PoE Budget
- 370 W
- Performance
- Latency (1000 Mbps): 5 µs
- Performance
- Latency (10 Gbps): 3 µs
- Performance
- Throughput: 132 Mpps
- Performance
- Routing/switching capacity: 176 Gbps
- Capacity
- IPv4 routing table entries: 512
- Capacity
- IPv6 routing table entries: 256
- Capacity
- VLAN IDs: 4094
- MAC Address Table Size
- 16384 entries
- Jumbo Frame Support
- 9216 bytes
- Routing Protocol
- OSPF, RIP-1, RIP-2, IGMP, OSPFv2, IGMPv3, OSPFv3, static IPv4 routing, static IPv6 routing, CIDR
- Remote Management Protocol
- SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTPS, TFTP, CLI, NTP, ICMP, RADIUS
- Encryption Algorithm
- SSL
- Authentication Method
- RADIUS, TACACS+, Secure Shell v.2 (SSH2), HWTACACS
- Features
- Flow control, BOOTP support, ARP support, load balancing, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, DiffServ support, High Availability, half duplex mode, full duplex mode, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Committed Access Rate (CAR), DHCP server, MLD snooping, Devic
- Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, ANSI/TIA-1057, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1r
- RAM
- 512 MB SDRAM
- Flash Memory
- 256 MB
- Status Indicators
- Port status, system
Dimensions & Weight
- Width
- 44 cm
- Depth
- 36 cm
- Height
- 4.36 cm
- Weight
- 8 kg
Environmental Parameters
- Min Operating Temperature
- -5 °C
- Max Operating Temperature
- 45 °C
- Humidity Range Operating
- 10 - 90% (non-condensing)
- Min Storage Temperature
- -40 °C
- Max Storage Temperature
- 70 °C
- Humidity Range Storage
- 5 - 95% (non-condensing)
Expansion / Connectivity
- Interfaces
- 48 x 1000Base-T RJ-45 PoE+
- Interfaces
- 4 x Gigabit / 10Gbit LAN SFP+
- Interfaces
- 1 x console RJ-45 management
- Interfaces
- 1 x micro-USB 5 pin USB header management
Manufacturer Warranty
- Service & Support
- Limited warranty - lifetime
Miscellaneous
- Rack Mounting Kit
- Included
- Compliant Standards
- Plug and Play, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, ICES-003 Class A, RoHS, UL 60950-1, IEC 60950-1, WEEE, EN 60825-1, FCC Part 15 B Class A, EN 60825-2, IPv6 Ready, EN 300 386, FDA 21 CFR, AS/NZS CISPR 32 Class A, YD/T993, IEC 62368-1, EN 55032, CAN/CSA-C22.2 No. 60950-1, VCCI-CISPR 32:2016 Class A, ETSI EN 300 386, EN 62368-1:2014/A11:2017, GB/T9254
